Release Notes - Autodesk Inventor 2015 Readme
Autodesk, Inc.

In a continuing effort to provide high quality products, Autodesk has released Autodesk Inventor 2015. This readme highlights significant known issues and provides useful information for operating Inventor.


Autodesk Inventor Fusion 2015 Manual Transmission

    Contents


Notes About Installation and Uninstallation

General

  • Please update your operating system before you install Autodesk Inventor 2015. Reboot your system after all security updates, and so on, are installed.
  • If you are using Windows 7 on a 64-bit system, please verify that you have the Microsoft fix for user mode callback exceptions KB976038. This fix ensures that Autodesk receives the correct data from Inventor error reports. For more information, and access to this fix and related Microsoft downloads, see Autodesk Technical Solution 15492718.
  • Close all Autodesk applications before installation, maintenance, or uninstallation of the software.
  • If you download the source files to a local folder with a name that contains non-English characters, ensure that the language in Regional Settings is consistent with the language name of the local folder.
  • If you choose to download and install from local files, to a system not within the same Domain, you may encounter a Security Warning dialog during the Application Manager installation. Select the Run option to continue the installation successfully.
  • Autodesk 360 Drive functionality is supported only within 2015 products by Autodesk Desktop Companion (sync) version 5 or above. Autodesk Desktop Companion version 5 is an optional component of AutoCAD and Inventor 2015 product installation.
  • To re-enable Autodesk 360 for for 2015 products, uninstall Autodesk 360 first, and then re-run the 2015 product installer.
  • When installed on the same system as Inventor 2014, the Configuration 360 add-in from Inventor 2015 is also available within the Inventor 2014 user interface. This add-in provides access to the online service and causes no issues within Inventor 2014.

Installation

  • Autodesk Inventor 2015 installs .NET 4.5 SP1 on Windows 7 operating systems. If you have Autodesk Inventor 2013 installed on the same computer, it is essential that you install Update 1 for Inventor 2013 SP1.1 to correct issues with running Autodesk Inventor 2013 with .NET 4.5.
  • If the installer prevents you from installing one or more products, pause the cursor over the red 'prohibited' circle beside the product name to get more information.
  • A new application tool Autodesk Application Manager is installed with Inventor. After you install Inventor, the Autodesk Privacy Policy displays. Accept the terms and then close the dialog box. The application is used for detecting Autodesk Service Pack and Updates later.

Uninstallation

  • During uninstallation, if error 1910 displays, click OK to continue. Then delete the shortcut that remains on the desktop. It is an issue from Microsoft, and there are also some similar issues discussions on Microsoft tech page, no solution for now.
  • When you uninstall a 2015 product, desktop companion also uninstalls. If any 2013, 2014, or 2015 versions of AutoCAD, Inventor, or Showcase are currently installed, the uninstallation of desktop companion includes removal of Autodesk 360 Drive functionality.
  • If you have any 2014 product installed as well, the Autodesk 360 Desktop Companion does not fully integrate into the Autodesk Uninstall Tool. When uninstalling, to uninstall the Autodesk 360 feature, use the Programs and Features control panel applet.
  • Autodesk Inventor 2015 includes a new Uninstall Tool that uninstalls the following components:
    • Autodesk Inventor Professional 2015
    • Autodesk ReCap (Works only on 64bit operating system)
    • Autodesk Inventor Content Center Libraries 2015 (Desktop Content)
    • Autodesk Vault Basic 2015 (Client)
    • Autodesk Revit Interoperability for Inventor 2015
    • Autodesk Material Library 2015
    • Autodesk Material Library Base Resolution Image Library 2015
    • Autodesk Material Library Low Resolution Image Library 2015
    • Autodesk DWG TrueView 2015 - English
    • Autodesk 360

    Installation includes the following components, but the Uninstall Tool does not detect them. You can uninstall them from the control panel:
    • Eco Materials Adviser for Autodesk Inventor 2015
    • Autodesk Application Manager
    • FARO LS 1.1.502.0
    • Mockup 360 addin 2015
    • Configurator 360 addin
  • Autodesk Inventor 2015 supports Windows 7 32-bit, Windows 7 64-bit, Windows 8 64-bit and Windows 8.1 64-bit.
  • Verify that you have administrator privilege on your local machine before installing Autodesk Inventor 2015.
  • The multimedia learning solutions require Flash player 10 (or higher). Download from get.adobe.com/flashplayer.
  • Adobe Reader is required to read documentation provided in PDF format. Download from get.adobe.com/reader.
  • Verify that you have 10 GB of free hard disk space or more for the self-extracted package.

Autodesk inventor fusion 2015 manual transmission

    Disk Requirements - Autodesk Inventor 2015


    Includes Inventor disk requirements and Inventor prerequisites disk requirements.


    SystemActual Disk Required
    Windows 32 bitTotal - 5.02 GBSystem drive (required) – 3.31 GB
    Windows 64 bitTotal - 8.19 GBSystem drive (required) – 5.67 GB

    Desktop Content LibraryActual Disk Required
    ANSI1,393 MB
    DIN 371 MB
    GOST926 MB
    ISO265 MB
    JIS & GB642 MB
    Feature3.22 MB
    Other1,813 MB
    Parker49.1 MB
    Routed Systems6.33 MB
    Sheet Metal45.2 MB
    Mold Metric56.6 MB

Installation Instructions

Before you begin...

  1. Install all Windows Updates that are pending on your machine and reboot:

      2. Windows 7: Windows Update is in the Control Panel, which is accessible from the Start menu.

      Windows 8: Windows Update is in the Control Panel, on the desktop Charms Bar, Settings menu.

      It is sometimes necessary to perform Windows Update multiple times to completely update your operating system.

  2. Verify that enough disk space is available on your machine to install Autodesk Inventor 2015.

Autodesk Inventor 2015 Download

Manual

Installation for Electronic Fulfillment users only:

  1. Download the appropriate Inventor 2015 installation file to a temporary location on your computer hard drive.
  2. To access the installer, double-click the self-extracting executable file. Temporary extraction is to your temp folder. Operating System errors regarding very long path names can occur if this temporary location is nested too many levels deep.
  3. We recommend that you use the default destination folder, which is 'C:Autodesk', as the self-extract destination folder name. After the file is extracted, the Inventor installer wizard launches automatically. If it does not launch, browse to the folder where all files were extracted and double-click setup.exe.
  4. To set preferences, in the Install > Configure Installation dialog box, click the expandable arrow.
  5. After configuration, begin the installation.
  6. When the installation is done, click Finish.
  7. A system reboot is sometimes required if you install a new Autodesk 360 with this installer.

Installation for DVD users only:

  1. Based on the bit type of your operating system, insert the appropriate DVD.
  2. The Inventor installer wizard launches automatically. If it does not launch, open the DVD disc and double-click setup.exe to start the installation.
  3. After configuration, confirm all your preferences are set as required before starting the installation.
  4. When the installation is done, click Finish.
  5. A system reboot is sometimes required if you install a new Autodesk 360 with this installer.

For more detailed instructions, please refer to the installation instructions provided with your delivered media containing Autodesk Inventor 2015.

To verify the installation was successful, start Inventor. On the Help menu, select About Autodesk Inventor. If the About box displays: Build: 159, Release: 2015, the installation was successful.

  • We recommend that you use a certified graphics card, and that your graphics card driver is up to date. See the Autodesk Inventor 2014 Release cards and drivers. The certified graphics cards and drivers are also applicable to Autodesk Inventor 2015.
  • For machines with certain ATI/AMD graphics cards, to avoid glitches in the graphics window, use the Performance graphics setting instead of the Quality setting.
  • For laptop computers with both an NVidia GeForce GPU and an Intel integrated GPU, change graphics from discrete GPU to Intel HD integrated graphics to ensure that Inventor 2015 works correctly.
  • Inventor uses TrueType and OpenType fonts. Other fonts are not supported.
  • For the document window title, Autodesk Inventor 2015 follows the setting 'Hide Extension for known file types' in Windows Explorer, like Microsoft Word or Excel.
  • When working with assemblies with more than 25000 components, we recommend that you use a 64-bit machine with 20 GB or more of physical RAM.

Direct Translators and Supported File Versions


    TranslatorImportExport
    AliasV10 or later
    CATIA V4All Revisions
    CATIA V5R6 - V5-6R2013R10 - V5-6R2013
    Creo Parametric1.0; 2.0
    IGESAll Revisions5.3
    JT7.0; 8.0; 8.1; 8.2; 9.0; 9.1; 9.2; 9.3; 9.4; 9.5; 10.07.0; 8.0; 8.1; 8.2; 9.0; 9.1; 9.2; 9.3; 9.4; 9.5; 10.0
    NXUnigraphics V13 - NX 9
    ParasolidUp to 26.09.0 - 26.0
    Pro/ENGINEERUp to Wildfire 5.0
    Pro/ENGINEER GraniteUp to 8.01.0 - 8.0
    Pro/ENGINEER NeutralN/AN/A
    RhinoUp to 5.0
    SATUp to 7.07.0
    SolidWorks2001 Plus – 2014
    STEPAP214, AP203E2AP214, AP203E2
    STLN/AN/A
    XGL/ZGLN/A

Autodesk Inventor Professional 2015

    Stress Analysis

    • Cannot detect contacts automatically on an invisible body unless you turn on the body visibility before automatic contact generation.

    Tooling

    • Cannot run a moldflow analysis on a mold design document that you reopen in the same Inventor session, but you can run the Moldflow analysis after you close and restart Inventor, and then reopen the document.

    Application Functionality

    • After you restart Inventor, the Configure Default Template dialog box reverts to the previous settings.
    • Inventor exits unexpectedly if you activate a project template that is restored on a server, and then click New.
    • In the Perform Minimum Rotation option, when you look at the XZ plane, the view rotates 180 degrees.

    Autodesk 360

    • When you upload Inventor files to Autodesk 360, synchronization does not always replicate file and folder structure, so to identify and delete them later without difficulty, do not move beta files to Autodesk 360.

    Enhanced Visualization

    • The appearance in a shaded drawing precise view is not always consistent with the appearance in previous Inventor releases.
    • When the view scale is set to a value lower than 1, the preview of drawing views is much brighter than the original appearance.
    • A model with transparent appearances or surface bodies sometimes disappears in a resized Inventor window with Ray Tracing.

    Express Mode

    • In-place changes to appearance for a component or surface for an express assembly display differently in full mode.
    • When you add a constraint using the Assemble command, the first selected component becomes invisible if you zoom in or out.
    • If you zoom out significantly after creating a section view, all components do not display when you zoom all.
    • When you in-place edit a sub-assembly and delete an envelope, the browser and graphics do not update correctly.

    iLogic

    • iLogic rule does not work for a disabled Direct Feature.

    Inventor Studio

    • Several dialog boxes, such as Render Image in Inventor Studio, collapse automatically when you move the cursor out of them.

    Materials/Appearances

    • Cannot change the Texture directory from the Projects dialog box, but you can change it in the Application Options dialog box.

    Part Modeling

    • Cannot do another operation after you click Cancel to exit an error message dialog box prompted by the Direct command, but you can click Close to exit.
    • Cannot open certain part files with freeform feature that was created in Beta builds.

    Point Cloud

    • Cannot attach point cloud workplane and point to point clouds.

    Sheet Metal

    • You cannot define an A-Side face or create a flat pattern if there are features below the EOF marker.
    • Inventor sometimes hangs when you create a flat pattern for certain imported sheet metal datasets that contains zero-radius Hem features.
    • Cannot create a cut normal on some sheet metal datasets that contains inner zero-radius bends.
    • Cannot deselect the picked sketch points when you edit the punch tool feature.
    • Inventor sometimes exits unexpectedly when you refold an unfolded imported dataset that contains zero-radius Hem features and sketches.
    • An error dialog box appears when you create a flat pattern for a part that contains reverse overlap square corners.

    Sketch

    • In a 32-bit operating system, when you add a tangent constraint to an interpolation spline and line, the result does not display until you drag either sketch entity.

    Translator

    • Cannot always read the exported JT files correctly with applications that do not follow the ISO JT format specification.
    • If the system locale does not support the localized body names of Parasolid and JT files, you cannot always import or export those files correctly.

    My Home

    • The Recently Used tab does not always display the last opened file and assembly components that you open from the top assembly.
    • The name of a closed file remains on the application title bar.
    • After you close the My Home page in the current Inventor session, it appears again when you close the last document.
    • After you open a document and then close it using Undo, you cannot change the project on the dropdown list in My Home.
    • In Windows 8 operating system, Inventor sometimes hangs when you load assembly Express mode or create a new file with My Home page opened.
    • Cannot create files with templates in the first line of More Templates if the system display size is set to Large-150%.

Legal Notice

    Autodesk Inventor, Autodesk Vault, Autodesk Data Management Server, Autodesk Productstream, Autodesk Autoloader, AutoCAD, AutoCAD Mechanical, and AutoCAD Electrical, are trademarks or registered trademarks of Autodesk, Inc. in the United States and/or other countries.


    Windows 7, Windows 8, Microsoft Word, and Microsoft Excel are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.


    Portions of this software copyright 1996-2008 Acresso Corporation.


    All other trademarks are the property of their respective owners.

    We thank all our customers who identified these issues and reported them to us. These reports give us the opportunity to improve the product and provide you with the best solution in mechanical design. We also thank you for your continued business and for the feedback regarding the content of this update release.


    Respectfully,


    Autodesk Inventor Product Team

Copyright © 2014 Autodesk, Inc.
